Features
Interface
- CLI, Telnet, Web GUI
Management
- Firmware upgrade
- Configuration backup
- DHCP Server/Client
- RMON (Remote Monitoring): group 1, 2, 3, 9
- Port Mirroring
- NTP (Network Time Protocol) synchronization
- LLDP (Link Layer Discovery Protocol)
- IPv4/IPv6
- SNMP v1/v2c/v3
Security
- MAC Address filtering
- Enable/Disable port
- Storm control
- System logging
- IEEE 802.1x LAN Access control
- Remote authentication through RADIUS and TACACS+
- Complex password support
- Multi-user login and privileged access management
- SSH for CLI and Telnet security
- SSL and HTTPS for web security
- ACL (Access Control List, up to 4096 entries)
Quality of Service (QoS)
- Priority Queues: 8 queues per port
- Traffic classification based on IEEE 802.1p CoS (Cost of Service), DSCP (Differentiated Services Code Point), WRR (Weighted Round Robin), and strict mode
- Rate Limiting (Ingress/Egress)
Layer 2 Features
Auto-negotiation for port speed and duplex
- Flow Control
- IEEE 802.3x full duplex mode
- Back-pressure half duplex mode
Redundant Protocols
- IEEE 802.1D STP
- IEEE 802.1w RSTP
- IEEE 802.1s MSTP
- EtherWAN’s Alpha-Ring network fault recovery
VLANs
- IEEE 802.1Q Tag VLANs
- GVRP
- GMRP
Link Aggregation
- Static Trunk (4 groups)
- IEEE 802.3ad LACP
IGMP Snooping v1/v2/v3
Switch Properties and Performance
Switching Fabric
- 5.6Gbps
Total VLAN Entries
- 256 (4096 VID)
MAC Table Size
- 8K
Packet Buffer Memory
- 2M bits
